The bench is designed to preserve sections of submersible pumps of domestic (5, 5A and 6 dimensions) and foreign (up to 562 dimensions) production with cooling liquid (antifreeze).
Description
ESP pump preservation bench consists of:
- a frame with 3 adjustable carriages located on it, on which the ESP is placed,
- supply head with an electric motor drive,
- pump station (the electric motor is connected to the head by a coupling) with a tank for cooling liquid (antifreeze) and an electric pump for supplying cooling liquid (antifreeze) to the ESP.
Technical specifications
| Max. bench power consumption | 5.5 kW. |
| ESP length | 6700 mm. |
| The volume of the tank for antifreeze | 500 l. |
| Total weight | 1400 kg. |
